Types of Impellers and How to Choose

Feb. 16, 2022

OEM Cast Iron Impeller



When pumping rags or solids, there are a few common impeller types to be familiar with. Understanding the differences in two vane, single vane, and vortex impellers will help you decide which is best for your ragging and solids issues. Let's take a closer look at different styles of impellers and their best uses.

Before we dive in, it's important to understand hydraulic efficiency. The concept is simple. Hydraulic efficiency is determined by how well a pump can convert supplied energy into useable output energy, or how well it converts the motor input power to fluid movement.  If two “units” of energy are supplied to a pump and its output is only one “unit”, its efficiency is 50%.

A typical pump is never 100% efficient because energy is always lost in the conversion process. The energy is lost in two main forms:  mechanical losses and volumetric losses.  Mechanical losses include the energy lost to fluid friction and internal pump forces. Volumetric losses include the energy lost as the result of internal fluid leakage or slippage within the pump.

Still with me? Good. Let's talk about different types of impellers.



Vortex Impeller

This design is similar to the semi-open impeller, but with more space in the volute.  Its design creates a whirlpool, or vortex, as liquid comes in, keeping solids away from the impeller and moving them through the discharge.  It is typically used in applications with trash and debris in the liquid, especially those with rags or stringy solids, making this impeller popular for sewage.  The solids-handling ability of this impeller is one of the highest, but it makes its efficiency one of the lowest.



Semi-Open Impeller

This impeller has a back shroud with vanes open to the incoming liquid.  It permits solids to pump out easily, but it will wear as solids contact the vanes.  With wear, the impeller clearances increase and slipping and recirculation occur, reducing the efficiency.  It clogs less than an enclosed impeller, but can still get wrapped up at times.  Luckily, it is easier to unclog than an enclosed impeller with its open-face design.



Enclosed Channel Impeller

This design consists of a backing, or shroud, with vanes and a front shroud, creating enclosed channels for liquids to travel through. It is good for passing large solids and offers some of the best efficiencies of solids-handling impellers.  The impeller maintains tight clearances with the wear rings, which keeps the inlet and pump pressures separate to reduce axial loads and maintain good efficiency.  Single vane versions are great at passing solids, but sometimes two vane designs can get fibrous solids snagged as it has more leading edges to catch debris.  If the pump does clog, it can be tricky to unclog because of the tight clearances and hard to reach channel spaces.



Screw Impeller

This impeller is used for pumping thick fluids and large, stringy solids.  Its screw-like, open channel design allows for passing these solids while minimizing shear, making it excellent for sensitive fluids as well.  It achieves high efficiency and is very resistant to clogging.  However, this design is intended more for end suction pumps and not submersible pumps.



Chopper/Cutter Impeller

The design typically incorporates hardened cutter bars that slice like scissors with the leading edges of the impeller vanes as they pass.  A chopper pump is selected when the fluid has solids that need to be shredded to smaller pieces before they enter the pump.  This helps prevent clogging and minimizes solid-related issues downstream.  Its ability to handle solids is dependent upon the sharpness of the cutter bars so the ability decreases with wear.  For efficiencies, it is on the lower end of the list.
