Butterfly Valve Disc

Butterfly Valve Disc - Ductile Iron Castings

Description:This Butterfly Valve Disc is a high-quality cast iron valve part designed for use in a wide range of industrial applications. Manufactured with precision from ductile iron GGG500-7, it features a hollow design, making it ideal for systems requiring durable and lightweight valve components.

Material:

• Ductile Iron GGG500-7

Weight:

• 69kgs

Applications:

• Pump & Valves

• Municipal Water Supply

• Agricultural Irrigation

• Petroleum Industry

• Chemical Industry

• Mining Industry

Keywords:

• Butterfly valve disc

• Hollow valve disc

• Valve part

• Sand casting

Place of Origin:

• Hebei, China

Brand Name:

• OEM (Original Equipment Manufacturer)

Process:

• Resin Sand Casting + Machining + Painting

Heat Treatment:

• No

Machining:

• CNC Vertical Lathe

• Drilling Machine

Production Procedures:

1. Incoming material inspection

2. Charge mixture

3. Moulding

4. Melting & Pouring

5. Shot blasting & grinding

6. Painting

7. Visual inspection

8. Machining

9. Process inspection

10. Cleaning

11. Leakage test

12. FQC (Final Quality Control)

13. Packing & Stocking

14. Pre-shipment inspection

15. Delivery

Tolerance:

• +/-0.05mm (or as per customer’s drawing)

Packing:

• Seaworthy Wooden Cases

Inspection:

• MT (Magnetic Test)

• UT (Ultrasonic Test)

• RT (Radiographic Test)

• 100% Visual Inspection

• 100% Gauge Check

• CMM (Coordinate Measuring Machine)

Standards:

• ASTM, AISI, DIN, BS, JIS, NF, AS

Certifications:

• ISO9001

• TS16949

• ISO14001

Supply Ability:

• 1000 Ton/Tons per Month

Port:

• Tianjin Xingang

Drawing:

• Provided by customer, or designed based on the sample. Formats: Pro/E, Auto-CAD, SOLIDWORK, CAXA, UG, CAD, CAM, CAE, STP, IGES, etc.

Mould:

• Designed and produced in-house based on customer drawings

FAQs:

1. How can I get a quotation?
   Please send us your drawing along with the required weight, material, and quantity.

2. If we don't have the drawing, can you create one for us?
   Yes, we can scan your sample and create the drawing for your confirmation.

3. What file formats do you accept?
   PDF, IGS, DWG, STEP, etc.

4. What is the size range for your castings?
   We can cast components from 1kg to 2000kg.

5. What is the MOQ?
   We accept a minimum order of 1 piece.

6. What are the lead times for samples and orders?
   Sample time: 6-8 weeks (including tooling construction).
   Order time: 4-6 weeks after sample approval, subject to complexity or quantity.

7. What are your payment terms?
   We accept L/C, D/P, and T/T.
   Tooling: 100% in advance, Order: 50% deposit, 50% before shipment.

8. What kind of patterns do you use?
   We typically use aluminum patterns for casting.
